Truth Table
Represent logical decisionmaking behavior with conditions, decisions, and actions
Libraries:
Stateflow
Description
The Truth Table block represents combinatorial logic design in a tabular format. You can use truth table blocks to model decision making behavior based on a set of conditions. For more information, see Use Truth Tables to Model Combinatorial Logic.
To implement control logic, Truth Table blocks use MATLAB^{®} as the action language.
Examples
Home Climate Control Using the Truth Table Block
Model a home climate control system by using a Truth Table block.
Ports
Input
Port_1 — Input port
scalar  vector  matrix
When you create input data in the Stateflow^{®} truth table using the Symbols pane, Stateflow creates a corresponding input port on the Truth Table block.
Data Types: single
 double
 int8
 int16
 int32
 int64
 uint8
 uint16
 uint32
 uint64
 Boolean
 fixed point
 enumerated
 bus
 string
Output
Port_1 — Output port
scalar  vector  matrix
When you create output data in the Stateflow truth table by using the Symbols pane, Stateflow creates a corresponding output port on the Truth Table block.
Data Types: single
 double
 int8
 int16
 int32
 int64
 uint8
 uint16
 uint32
 uint64
 Boolean
 fixed point
 enumerated
 bus
 string
Parameters
To edit block parameters interactively, use the Property Inspector. From the Simulink^{®} Toolstrip, on the Simulation tab, in the Prepare gallery, select Property Inspector.
Note
Truth Table blocks also have Subsystem (Simulink) block parameters that you can access by rightclicking the block and clicking Block Parameters (Subsystem). However, updating these block parameters is not recommended.
Update method — Method to update or wake up a Stateflow truth table
Inherited
(default)  Discrete
 Continuous
Method to update or wake up a Stateflow truth table, specified as
Inherited
, Discrete
,
or Continuous
.
Inherited
Input from the Simulink model determines when the truth table wakes up during a simulation (default).
If you define input events for the truth table, the Stateflow truth table is explicitly triggered by a signal on its trigger port originating from a connected Simulink block. You can set this trigger input event to occur in response to a Simulink signal. The Simulink signal can be
Rising
,Falling
, orEither
(rising and falling), or in response to aFunction Call
. For more information, see Activate a Stateflow Chart by Sending Input Events.If you do not define input events, the Stateflow truth table implicitly inherits triggers from the Stateflow model. These implicit events are the discrete or continuous sample times of the Stateflow signals providing inputs to the truth table. If you define data inputs, the truth table awakens at the rate of the fastest data input. If you do not define any data input for the truth table, the truth table wakes up as defined by the execution behavior of its parent subsystem.
Discrete
The Simulink model generates an implicit event at regular time intervals to awaken the Stateflow truth table at the rate that you specify in the Sample Time truth table parameter. Other blocks in the Simulink model can have different sample times.
Continuous
The Stateflow truth table updates its state during major time steps only, although it computes outputs and local continuous variables during major and minor time steps. For more information, see ContinuousTime Modeling in Stateflow.
Programmatic Use
To set the block parameter value programmatically, access the Stateflow.TruthTableChart
object of the block and change
the object property by using dot notation.
Parameter:  ChartUpdate
Values:  "INHERITED" (default)  "CONTINUOUS"  "DISCRETE"
Sample time — Time interval that a Stateflow truth table wakes up during simulation
1
(default)  scalar  vector
Time interval that a truth table wakes up during simulation, specified by
a scalar or a vector. The default time interval is 1
,
which indicates that the Stateflow truth table inherits the sample time from Simulink.
Do not use the Sample Time parameter in the Subsystem block parameters. Instead, use the Property Inspector.
Dependencies
To enable this parameter, set Update method to
Discrete
.
Programmatic Use
To set the block parameter value programmatically, access the Stateflow.TruthTableChart
object of the block and change
the object property by using dot notation.
Parameter:  SampleTime
Values:  "1" (default)  string scalar  character vector
Data Types:  string  char
Advanced
Saturate on integer overflow — Whether data saturates on integer
overflow
on
(default)  off
Whether the data in the truth table saturates on integer overflow. When you clear this parameter, the data in the truth table wraps on integer overflow. For more information, see Handle Integer and Enumeration Overflow for Chart Data.
Programmatic Use
To set the block parameter value programmatically, access the
Stateflow.TruthTableChart
object of the block and
change the object property by using dot notation.
Parameter:  SaturateOnIntegerOverflow
Values:  true or
1 (default)  false or 0
Data Types:  logical
Support variablesize arrays — Whether the truth table supports variable size data
on
(default)  off
Whether the truth table supports variablesize data. For more information, see Declare VariableSize Data in Stateflow Charts.
Programmatic Use
To set the block parameter value programmatically, access the
Stateflow.TruthTableChart
object of the block and
change the object property by using dot notation.
Parameter:  SupportVariableSizing
Values:  true or
1 (default)  false or 0
Data Types:  logical
Treat dimensions of length 1 as fixed size — Whether truth table treats output data with dimension of length 1 as fixed size
on
(default)  off
Since R2023a
Whether the truth table treats output data with a dimension of length 1 as fixed size. When you select this parameter, the truth table treats output data that have at least one dimension of length 1 as fixed size, regardless of whether you enable the Variable size data property. When you clear this parameter, the truth table treats data with the Variable size property enabled as variable size.
Programmatic Use
To set the block parameter value programmatically, access the
Stateflow.TruthTableChart
object of the block and
change the object property by using dot notation.
Parameter:  TreatDimensionOfLengthOneAsFixedSize
Values:  true or
1 (default)  false or 0
Data Types:  logical
Overspecification — Level of diagnostic when truth table is overspecified
"Error"
(default)  "Warning"
 "None"
Level of diagnostic action when the truth table is overspecified,
specified as "Error"
, "Warning"
,
or "None"
. For more information, see Correct Overspecified and Underspecified Truth Tables.
Programmatic Use
To set the block parameter value programmatically, access the
Stateflow.TruthTableChart
object of the block and
change the object property by using dot notation.
Parameter:  OverSpecDiagnostic
Values:  "Error" (default)  "Warning"  "None"
Fixedpoint properties
Treat these inherited Simulink signal types as fi objects — Inherited Simulink signals to treat as fi
objects
Fixedpoint
(default)  Fixedpoint & Integer
Inherited Simulink signals to treat as FixedPoint Designer™
fi
objects, specified as one of these values:
Fixedpoint
— The truth table treats all fixedpoint inputs asfi
objects.Fixedpoint & Integer
— The truth table treats all fixedpoint and integer inputs asfi
objects.
This parameter applies only to truth tables that use MATLAB as the action language.
Programmatic Use
To set the block parameter value programmatically, access the
Stateflow.TruthTableChart
object of the block and
change the object property by using dot notation.
Parameter:  TreatAsFi
Values:  "Fixedpoint" (default)  "Fixedpoint & Integer"
MATLAB Chart fimath — Default fimath
object properties
Same as MATLAB
(default)  Specify Other
Default fimath
object properties for the truth table,
specified as one of these values:
Same as MATLAB
— The truth table uses the samefimath
object properties as the current defaultfimath
object. The text box is dimmed and displays the current globalfimath
object in readonly form.Specify other
— Specify your ownfimath
object in the text box.
For more information, see fimath Object Construction (FixedPoint Designer).
Programmatic Use
To set the block parameter value programmatically, access the
Stateflow.TruthTableChart
object of the block and
change the object property by using dot notation.
Parameter:  EmlDefaultFimath
Values:  "Same as MATLAB
Default" (default)  "Other:UserSpecified"
Extended Capabilities
C/C++ Code Generation
Generate C and C++ code using Simulink® Coder™.
HDL Code Generation
Generate VHDL, Verilog and SystemVerilog code for FPGA and ASIC designs using HDL Coder™.
HDL Coder™ provides additional configuration options that affect HDL implementation and synthesized logic.
You can use a tunable parameter in a Truth Table block intended for HDL code generation. For details, see Generate DUT Ports for Tunable Parameters (HDL Coder).
This block has one default HDL architecture.
ConstMultiplierOptimization  Canonical signed digit (CSD) or factored CSD optimization. The
default is
ConstrainedOutputPipeline  Number of registers to place at
the outputs by moving existing delays within your design. Distributed
pipelining does not redistribute these registers. The default is

DistributedPipelining  Pipeline register distribution,
or register retiming. The default is
InputPipeline  Number of input pipeline stages
to insert in the generated code. Distributed pipelining and constrained
output pipelining can move these registers. The default is

OutputPipeline  Number of output pipeline stages
to insert in the generated code. Distributed pipelining and constrained
output pipelining can move these registers. The default is

ResetType  Suppress reset logic generation. The default is
SharingFactor  Number of functionally equivalent resources to map to a single shared resource. The default is 0. See also Resource Sharing (HDL Coder).
The block participates in these HDL optimizations to optimize the speed, and area.
Speed and Area Optimization
Optimization  Description

Distributed Pipelining (HDL Coder)  Distributed pipelining, or register retiming, is a speed optimization that moves existing delays in a design to reduce the critical path while preserving functional behavior.
Resource Sharing (HDL Coder)  Resource sharing is an area optimization in which HDL Coder identifies multiple functionally equivalent resources and replaces them with a single resource.
Delay Balancing (HDL Coder)  When optimizations or block implementation options introduce delays along the critical path in a model, Delay Balancing detects introduction of new delays along one path, and then inserts matching delays on the other paths.
ClockRate Pipelining (HDL Coder)  Clockrate pipelining is an optimization framework in HDL Coder that allows other speed and area optimizations to introduce latency at the clock rate.
Adaptive Pipelining (HDL Coder)  Adaptive pipelining optimization creates patterns or combination of blocks with registers that can improve the achievable clock frequency and reduce the area usage on the FPGA boards by inserting pipeline registers to the blocks in your design.
Critical Path Estimation (HDL Coder)  To quickly identify the most likely critical path in your design, use Critical Path Estimation. Critical path estimation speeds up the iterative process of finding the critical path. To know blocks that are characterized in critical path estimation, see Characterized Blocks (HDL Coder).
To learn about restrictions, see Introduction to Stateflow HDL Code Generation (HDL Coder).
When you apply optimizations, the block has these limitations:
HDL optimizations are not supported for the block that has Trigger port.
PLC Code Generation
Generate Structured Text code using Simulink® PLC Coder™.
FixedPoint Conversion
Design and simulate fixedpoint systems using FixedPoint Designer™.
Version History
Introduced before R2006aR2023a: Specify how to treat output data with dimension of length 1
With the new parameter Treat dimensions of length 1 as fixed size, you can specify how truth tables treat output data when at least one dimension has length 1. Prior to R2023a, truth tables treat output data with at least one dimension of length 1 as fixed size, regardless of whether you enable the Variable size data property.
