2-D affine geometric transformation

An `affine2d`

object stores information about a 2-D affine
geometric transformation and enables forward and inverse transformations.

You can create an `affine2d`

object using the following
methods:

`imregtform`

— Estimate a geometric transformation that maps a moving image to a fixed image using similarity optimization.`imregcorr`

— Estimate a geometric transformation that maps a moving image to a fixed image using phase correlation.`fitgeotrans`

— Estimate a geometric transformation that maps pairs of control points between two images.`randomAffine2d`

— Create a randomized 2-D affine transformation.The

`affine2d`

function described here.

`tform = affine2d`

creates an `affine2d`

object with default property settings that correspond to the identity
transformation.

`tform = affine2d(`

sets the
property `T`

)`T`

as the specified valid affine transformation
matrix.

`invert` | Invert geometric transformation |

`isRigid` | Determine if transformation is rigid transformation |

`isSimilarity` | Determine if transformation is similarity transformation |

`isTranslation` | Determine if transformation is pure translation |

`outputLimits` | Find output spatial limits given input spatial limits |

`transformPointsForward` | Apply forward geometric transformation |

`transformPointsInverse` | Apply inverse geometric transformation |
