Serial Link Design Concepts

Learn the basics of serial link design projects using the Serial Link Designer app

Using the Serial Link Designer app, you can analyze serial link projects for pre-layout and post-layout simulations. The app uses an iterative and sequential process to find an optimal solution based on the design requirements. You can organize the data using transfer nets.

The app allows you to design, simulate, and test AMI models with PAMn signaling. You can also enable different clock modes. For faster processing, the app allows you to run simulations in parallel if you have license to Parallel Computing Toolbox™.


Serial Link DesignerAnalyze PCB designs for serial link applications (Since R2021b)
