DVB-S2 Symbol Demodulator

Demodulate complex constellation symbol to set of LLR values or data bits according to DVB-S2 standard

  • Library:
  • Wireless HDL Toolbox / Modulation

  • DVB-S2 Symbol Demodulator block

Description

The DVB-S2 Symbol Demodulator block demodulates complex data symbol to log-likelihood ratio (LLR) values or data bits based on the modulation types supported by the Digital Video Broadcast Satellite Second Generation (DVB-S2) standard [1]. The block accepts equalized complex data symbols and a samplecontrol bus or a valid signal. It outputs demodulated LLR values or data bits and a samplecontrol bus or a valid signal based on the selected output type. The block provides an option to select the output type as vector or scalar. The number of demodulated LLR values or data bits for a given symbol depends on the modulation type, as shown in this table.

Modulation TypeNumber of LLR Values or Data Bits Per Symbol
pi/2-BPSK1
QPSK2
8-PSK3
16-APSK4
32-APSK5

The block provides an architecture suitable for HDL code generation and hardware deployment. You can use this block in the development of a DVB-S2 receiver.

Ports

Input

expand all

Data symbols, specified as a real- or complex-valued scalar.

double and single data types are supported for simulation, but not for HDL code generation.

For HDL code generation, the input data type must be signed fixed point and the maximum input word length the block supports is 32 bits.

Data Types: single | double | int8 | int16 | int32 | signed fixed point
Complex Number Support: Yes

Control signals accompanying the sample stream, specified as a samplecontrol bus. The bus includes the start, end, and valid control signals, which indicate the boundaries of the frame and the validity of the samples.

  • start — Indicates the start of the input frame

  • end — Indicates the end of the input frame

  • valid — Indicates that the data on the input data port is valid

For more details, see Sample Control Bus.

Data Types: bus

Control signal that indicates if the input data is valid. When this value is 1 (true), the block accepts the values on the data input port. When this value is 0 (false), the block ignores the values on the data input port.

Dependencies

To enable this port, set the Output type parameter to Scalar.

Data Types: Boolean

Modulation index, specified as 0, 1, 2, 3, or 4. Each value represents a specific modulation type, as shown in this table.

Modulation IndexModulation Type
0 QPSK
18-PSK
216-APSK
332-APSK
4 pi/2-BPSK

If you specify a value other than ones listed in this table, the block displays a warning message and applies QPSK modulation. Specify this value in fixdt(0,3,0) format.

Dependencies

To enable this port, set the Modulation source parameter to Input port.

Data Types: single | double | fixdt(0,3,0)

Code rate index, specified as 5, 6, 7, 8, 9, or 10. Each value represents a specific code rate, as shown in this table.

Code Rate IndexCode Rate
5 2/3
63/4
74/5
85/6
9 8/9
109/10

The code rates in this table are applicable for the modIdx input port values 2 and 3, which imply 16-APSK and 32-APSK modulations, respectively. When you set the modIdx port values to 0, 1, or 4, the block ignores the codeRateIdx input port values.

Specify this value in fixdt(0,4,0) format.

Dependencies

To enable this port, set the Modulation source parameter to Input port.

Data Types: single | double | fixdt(0,4,0)

Noise variance, specified as a real-valued positive scalar.

This value must be of data type fixdt(0,k,m), where k is less than or equal to 16 and m is less than or equal to k.

When the Output type parameter is set to Scalar, the block samples the nVar port when the input valid is 1.

When the Output type parameter is set to Vector, the block samples the nVar port based on the samplecontrol bus.

double and single data types are supported for simulation, but not for HDL code generation.

Dependencies

To enable this port, select the Enable noise variance input port parameter.

Data Types: single | double | uint8 | uint16 | unsigned fixed point

Output

expand all

Demodulated LLR values or data bits, returned as a scalar when the Output type parameter is set to Scalar and as an 8-element real-valued column vector when the Output type parameter is set to Vector.

  • When the Decision type parameter is set to Approximate log-likelihood ratio:

    • For double and single inputs, the output data type is the same as the input data type.

    • For fixed point inputs, the block provides the output with an integer bit growth of 14 bits when you select the Enable noise variance input port parameter and with an integer bit growth of 3 bits when you clear the parameter.

  • When the Decision type parameter is set to Hard, the output data type is Boolean for any supported input data type.

Data Types: single | double | int8 | int16 | int32 | Boolean | fixed point

Control signals accompanying the sample stream, returned as a samplecontrol bus. The bus includes the start, end, and valid control signals, which indicate the boundaries of the frame and the validity of the samples.

  • start — Indicates the start of the output frame

  • end — Indicates the end of the output frame

  • valid — Indicates that the data on the output data port is valid

For more details, see Sample Control Bus.

Data Types: bus

Control signal that indicates if data from the data output port is valid. When this value is 1 (true), the block returns valid data on the data output port. When this value is 0 (false), the values on the data output port are not valid.

Dependencies

To enable this port, set the Output type parameter to Scalar.

Data Types: Boolean

Control signal that indicates when the block is ready to accept new input data. When this value is 1 (true), the block accepts input data in the next time step. When this value is 0 (false), the block ignores the input data in the next time step.

The ready signal remains 0 (false) until the block outputs data of the corresponding input data symbol. The number of clock cycles the ready signal remains 0 (false) depends on the selected modulation type.

Dependencies

To enable this port, set the Output type parameter to Scalar.

Data Types: Boolean

Parameters

expand all

To specify the modulation type from the Modulation parameter, select Property. To specify the modulation type from the modIdx port during run time, select Input port.

Select the modulation type.

Dependencies

To enable this parameter, set the Modulation source parameter to Property.

Select the code rate.

Dependencies

To enable this parameter set the Modulation source parameter to Property and the Modulation parameter to 16-APSK or 32-APSK.

Select the demapping type.

  • Approximate log-likelihood ratio — Demap data symbols to LLR values. This LLR value for each bit indicates how likely the bit is 1 or 0.

  • Hard — Demap data symbols to bits 1 or 0.

Select the type of output as Vector or Scalar.

  • Vector — Use this option to receive data in 8-element column vector format from the output data port.

  • Scalar — Use this option to receive data in scalar format from the output data port.

Select this parameter to perform symbol demodulation with a normalized constellation. Clear this parameter to perform symbol demodulation using the constellation defined as per the standard [1].

When you specify 0, 1, or 4 using the modIdx input port or set the Modulation parameter to QPSK, 8-PSK, or pi/2-BPSK, the block ignores this parameter during its operation.

Dependencies

To enable this parameter, set the Modulation source parameter to Input port or set the Modulation source to Property and the Modulation parameter to 16-APSK or 32-APSK.

Select this parameter to enable the noise variance input port.

Dependencies

To enable this parameter, set the Decision type parameter to Approximate log-likelihood ratio.

Algorithms

expand all

The block uses the soft-decision approximate LLR or hard-decision algorithms to demodulate complex data symbols according to the DVB-S2 standard.

In soft-decision approximate LLR, the block computes the approximate LLR by using the nearest constellation point to the received signal with a 0 (or 1) at that bit position. The LLR for a bit b can be defined as:

LLR(b)=1σ2(minsS1|zs|2minsS0|zs|2)

where σ2 is the noise variance, z is the received sequence, s is a symbol from the constellation, and S0, S1 is the set of symbols that corresponds to bits being 0 and 1 respectively. For more information, see [2].

In hard-decision algorithm, the block computes the magnitude and phase angle of the input data and outputs the data bits based on the decision boundaries. For more information, see [3].

References

[1] ETSI Standard EN 302 307 V1.4.1: Digital Video Broadcasting (DVB); Second generation framing structure, channel coding and modulation systems for Broadcasting, Interactive Services, News Gathering and other broadband satellite applications (DVB-S2), European Telecommunications Standards Institute, Valbonne, France, 2005-03.

[2] Viterbi, A.J. “An Intuitive Justification and a Simplified Implementation of the MAP Decoder for Convolutional Codes.” IEEE Journal on Selected Areas in Communications 16, no. 2 (February 1998): 260–64. https://doi.org/10.1109/49.661114.

[3] Sebesta, J. “Efficient Method for APSK Demodulation.” Selected Topics on Applied Mathematics, Circuits, Systems, and Signals (P. Pardalos, N. Mastorakis, V. Mladenov, and Z. Bojkovic, eds.). Vouliagmeni, Athens, Greece: WSEAS Press, 2009.

Extended Capabilities

Version History

Introduced in R2021b

expand all

Behavior changed in R2022a
