Factor relating two SE(2) poses
factorTwoPoseSE2 object contains factors that relate pairs of
poses in the SE(2) state space for a
F = factorTwoPoseSE2(
F, with the
node identification numbers property
NodeID set to
specifies properties using one or more name-value arguments. For example,
F = factorTwoPoseSE2(
factorTwoPoseSE2([1 2],Measurement=[1 5 7]) sets the
Measurement property of the
[1 5 7].
NodeID — Node ID numbers
N-by-2 matrix of nonnegative integers
This property is read-only.
Node ID numbers, specified as an N-by-2 matrix of nonnegative
integers, where N is the total number of desired factors. Each row
represents a factor that connects to two nodes of type
the specified node IDs in the factor graph. The rows are of the form
If a factor in the
factorTwoPoseSE2 object specifies an ID that does not
correspond to a node in the factor graph, the factor graph automatically creates a node
of the required type with that ID and adds it to the factor graph when adding the factor
to the factor graph.
You must specify this property at object creation.
Measurement — Measured relative pose
zeros(N,3) (default) | N-by-3 matrix
Measured relative pose, specified as a N-by-3 matrix, where each row is of the form [dx dy dtheta]. N is the total number of factors. dx and dy are the change in position in x and y, respectively, and dtheta is the angle between the two positions.
Information — Information matrix associated with measurements
eye(3) (default) | 3-by-3 matrix | 3-by-3-N array
Information matrix associated with the measurement, specified as a 3-by-3 matrix or
a 3-by-3-N matrix. N is the total number of
factors specified by this
factorTwoPoseSE2 object. Each information matrix
corresponds to the measurements of the specified nodes in
If you specify this property as a 3-by-3 matrix when
contains more than one row, the information matrix corresponds to all measurements in
|Get node type of node in factor graph|
FactorTwoPoseSE2 Object to Factor Graph
Create measurement vector, information matrix, and a node ID number vector. Create a
factorTwoPoseSE2 object, specifying the node IDs, measurement, and information as arguments.
nodeID = [1 2]; measure = [5 5 pi/2]; info = rand(3,3); f = factorTwoPoseSE2(nodeID,Measurement=measure,Information=info);
Create a default factor graph and add the factor to the graph using the
g = factorGraph; addFactor(g,f);
C/C++ Code Generation
Generate C and C++ code using MATLAB® Coder™.
Version HistoryIntroduced in R2022a
R2023a: Specify multiple factors
Information properties now accept additional rows to specify
