successors

Node successors

Syntax

sucIDs = successors(G,nodeID)

Description

sucIDs = successors(G,nodeID) returns the successor nodes of the node in directed graph G specified by nodeID. The successor nodes form directed edges with nodeID as the source node, and sucIDs as the target nodes.

Examples

Node Successors

Create and plot a directed graph and determine the successor nodes of node 'a'.

s = [1 1 1 2 2 3 3 7 8];
t = [2 3 4 5 6 7 8 5 5];
names = {'a' 'b' 'c' 'd' 'e' 'f' 'g' 'h'};
G = digraph(s,t,[],names);
plot(G)

sucIDs = successors(G,'a')

sucIDs = 3x1 cell
    {'b'}
    {'c'}
    {'d'}

Input Arguments

G — Input graph

digraph object

Input graph, specified as a digraph object. Use digraph to create a directed graph object.

Example: G = digraph([1 2],[2 3])

nodeID — Node identifier

node index | node name

Node identifier, specified as one of the values in this table.

Value	Example
Scalar node index	1
Character vector node name	'A'
String scalar node name	"A"

Example: sucIDs = successors(G,3) finds the successor nodes of node 3.

Output Arguments

sucIDs — Successor node IDs

node indices | node names

Successor node IDs, returned as a node indices or node names.

• If nodeID is a numeric node index, then sucIDs contains numeric node indices.

• If nodeID is a node name, then sucIDs contains node names.

Tips

• For multigraphs with multiple edges between the same two nodes, the output of outedges can be longer than that of successors, since there can be multiple outgoing edges to some of the successors.

Extended Capabilities

C/C++ Code Generation

Generate C and C++ code using MATLAB® Coder™.

Usage notes and limitations:

• The node identifier nodeID must be a numeric node index of the input graph G. Node name is not supported.

Version History

Introduced in R2015b
