Hardware Support

Capabilities and Features

SoC Blockset Support Package for Xilinx® Devices enables you to design, evaluate, and implement SoC hardware and software architectures on Xilinx FPGA and Zynq® SoC boards.

Using this support package along with Embedded Coder and HDL Coder, you can build, load, and execute SoC models on Xilinx FPGA and Zynq SoC boards. This enables you to verify your designs on real hardware and perform measurements with real-time monitoring and visualization. You can:

  • Deploy SoC applications to hardware using the product’s SoC Builder workflow to prototype and implement on supported boards
  • Capture I/O signals from hardware testing for reuse in simulation or in further hardware testing
  • Perform on-hardware profiling.

The support package enables these capabilities by inserting monitor IP into programmable logic and by instrumenting generated C code to transmit run-time information back to MATLAB sessions.

Supported Hardware

SoC Blockset supports execution on Xilinx devices shown in this table.

Device Family


Xilinx Artix®-7

Artix-7 35T Arty FPGA Development Board

Xilinx Kintex®-7

Kintex-7 KC705

Xilinx Zynq®

Zynq-7000 ZC706


Xilinx Zynq UltraScale+™

Zynq UltraScale+ MPSoC ZCU102 Evaluation Kit
Zynq UltraScale+ RFSoC ZCU111 Evaluation Kit
Zynq UltraScale+ RFSoC ZCU216

This support package supports hardware configurations for video and SDR applications.
