Write to one or more output channels not handled by specific blocks
Simulink Desktop Real-Time
Connect to and write to hardware sinks requiring specialized driver support that other Simulink® Desktop Real-Time™ output blocks do not provide. The Other Output block is rarely used and only for a few drivers. For details, see the documentation for the driver that you intend to use.
If none of the available blocks, including Other Output, provide what you need, you can create your own I/O blocks to work with Simulink Desktop Real-Time applications. For more information, see Custom I/O Driver Basics.
Data— Data to write to output channels
The data type and range of the input value depend upon the capabilities of the board.
Output channels— Channel vector that selects other output channels
1(default) | vector
Enter a channel vector that selects the other output channels that you are using on this board. The vector can be any valid MATLAB® vector form. For example, to select the first two other output channels, enter:
Optional parameters— Specify optional parameters that the driver requires
0(default) | vector
See the manufacturer data sheet for the required values.
Initial value— Specify the value that the channel generates before execution starts
Enter the initial value for each output channel that you entered in the Output channels box.
Final value— Specify the value that the channel generates after execution ends
Enter the final value for each output channel that you entered in the Output channels box.
