Inline invariant signals

Transform symbolic names of Invariant signals in generated code

Model Configuration Pane: Code Generation / Optimization

Description

The Inline invariant signals parameter instructs the code generator to transform symbolic names of invariant signals into constant values.

Category: Optimization

Dependencies

This parameter is enabled when you set Default parameter behavior to Inlined.

Settings

off (default) | on
On

Simulink® Coder™ software uses the numerical values of model parameters, instead of their symbolic names, in generated code. An invariant signal is not inline if it is nonscalar, complex, or the block inport the signal is attached to takes the address of the signal.

Off

Uses symbolic names of model parameters in generated code.

Recommended Settings

ApplicationSetting
DebuggingOff
TraceabilityOff
EfficiencyOn
Safety precautionNo impact

Programmatic Use

Parameter: InlineInvariantSignals
Type: character vector
Value: 'on' | 'off'
Default: 'off'

Version History

Introduced before R2006a
