Signal Integrity and Mixed Signal Design and Analysis
R2026bSignal integrity and mixed signal applications
Design and analyze PCB layout performance, crosstalk, and interconnects using RF PCB Toolbox™.
Featured Examples
Create and Analyze PCB Interconnects Using Custom Traces
Create and analyze PCB traces.
Routing Discipline to Reduce Crosstalk
Analyze surface currents and follow routing discipline on a PCB trace.
Design and Analyze Microstrip-to-Stripline Transition for Multilayer Printed Circuit Board
Design and analyze a microstrip-to-stripline (MS-to-SL) vertical transition for multilayer printed circuit boards (PCBs), which is essential for high-speed digital and RF applications [1].
Analyzing Crosstalk Between PCB Traces
Analyze crosstalk between PCB traces.
